Description
Level Up.
A mountain bike built to raise your game and ignite a passion for the trail. Designed for the mountains and ready for anything.
Where it thrives
Low-impact trails, gravel roads, leisurely ride
What it’s built for
Handling, durability
Highlights
- Light and durable SmartForm C3 Alloy frame
- SR Suntour XCT suspension fork, 100mm travel
- Shimano 8-speed shifting w/double chainring crank / Shimano hydraulic disc brakes
Technology
SAVE Micro-Suspension
Delivers a smoother, more controlled ride thanks to strategically engineered flex zones built into the frame’s rear triangle.
Slack and Stable
A slack 68° head angle creates exceptionally stable handling so that you can charge the descents with confidence.
Right-Sized Wheels
The smaller sizes of Trail roll on 27.5″ wheels, while the larger sizes come with 29″ wheels to deliver the best blend of fit, fast and fun for every rider.
StraightShot Internal Cable Routing
For an integrated look and easy maintenance, the shift and dropper post cables route cleanly through the StraightShot window in the down tube, while the rear brake line is secured outside the frame.
SmartForm C3 Alloy
Simple yet sophisticated aluminum construction yields a light, lively frame that outperforms anything in its class.
SAVE Micro-Suspension
Delivers a smoother, more controlled ride thanks to strategically engineered flex zones built into the frame’s rear triangle.
Slack and Stable
A slack 68° head angle creates exceptionally stable handling so that you can charge the descents with confidence.
Right-Sized Wheels
The smaller sizes of Trail roll on 27.5″ wheels, while the larger sizes come with 29″ wheels to deliver the best blend of fit, fast and fun for every rider.
StraightShot Internal Cable Routing
For an integrated look and easy maintenance, the shift and dropper post cables route cleanly through the StraightShot window in the down tube, while the rear brake line is secured outside the frame.
SmartForm C3 Alloy
Simple yet sophisticated aluminum construction yields a light, lively frame that outperforms anything in its class.
SAVE Micro-Suspension
Delivers a smoother, more controlled ride thanks to strategically engineered flex zones built into the frame’s rear triangle.
Slack and Stable
A slack 68° head angle creates exceptionally stable handling so that you can charge the descents with confidence.
Right-Sized Wheels
The smaller sizes of Trail roll on 27.5″ wheels, while the larger sizes come with 29″ wheels to deliver the best blend of fit, fast and fun for every rider.
StraightShot Internal Cable Routing
For an integrated look and easy maintenance, the shift and dropper post cables route cleanly through the StraightShot window in the down tube, while the rear brake line is secured outside the frame.
Specs
DETAILS
- Platform Trail
- Model Name Trail 6
- Model Code C26601M
FRAMESET
- Frame SmartForm C3 Alloy, SAVE, 1-1/8″ headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, BSA-73
- Fork SR Suntour XCT, 100mm, coil, 42mm offset (27.5″) 46mm offset (29″)
- Headset Semi-Integrated, 1-1/8″
DRIVETRAIN
- Rear Derailleur Shimano Acera
- Front Derailleur Shimano Altus, 34.9 clamp
- Shifters Shimano M315 Rapidfire Plus, 8-speed
- Chain KMC X8, 8-speed
- Crank Prowheel, 36/22
- Rear Cogs Sunrace, 11-34, 8-speed
- Bottom Bracket Sealed bearing cartridge, square taper
BRAKES
- Brakes Tektro M275 hydraulic disc, 160/160mm rotors
- Brake Levers Tektro hydraulic disc
WHEELS
- Rims WTB SX19, 32h
- Front Hub Shimano HBTX 505
- Rear Hub Shimano FHTX505
- Spokes Stainless Steel, 14g
- Tires WTB Ranger Comp, 29×2.25″ (27.5×2.25″ – XS, SM), DNA Compound
- Tire Size 2.25
- Wheel Size 29
- Front Tire WTB Ranger Comp, 29×2.25″ (27.5×2.25″ – XS, SM), DNA Compound
- Rear Tire WTB Ranger Comp, 29×2.25″ (27.5×2.25″ – XS, SM), DNA Compound
COMPONENTS
- Handlebar Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm
- Stem 6061 Alloy, 31.8, 7°
- Grips Cannondale Dual-Density
- Saddle Cannondale Stage 3
- Seatpost Cannondale 3, 6061 Alloy, 31.6 x 350mm (XS – SM), 400mm (MD-XL)
